LS/PD MULTI 3 CI

LS/PD MULTI3 CI

GTIN: 4008321916648 Folding box / 1 Show all packages
Download data sheet
Contact sales
Our warranty conditions

PRODUCT DETAILS

Product benefits
  • Particularly small construction
Areas of application
  • Offices
  • Corridors
  • Classrooms
  • Training rooms
  • Stairways
  • Sanitary areas
Product features
  • Ceiling installation sensor with moveable sensor head
  • Connection via four-pole screw terminal or modular 4c4p-connector
Equipment / Accessories
  • Surface mounting in connection with SENSOR KIT
  • Suitable for MULTIeco, DIM MULTIeco, DALI MULTIeco control unit
  • Suitable for DALI Professional Sensor Coupler
Electrical data
Mains frequency 0 Hz
Dimensions & Weight
Length 50.00 mm
Width 50.00 mm
Height 25.00 mm
Diameter 50,0 mm
Product weight 30.00 g
Colors & materials
Product color White
Temperatures & operating conditions
Ambient temperature range 0…+50 °C
Capabilities
Dimmable No
Maximum installation height 4 m
Detection area 6 m 1)
Detection angle 80 ° 2)
Type of installation On-top ceiling mounting/Ceiling integration
Operating range, light sensor 20…600 lx 3)
1) Maximum diameter
2) Approximately
3) Approximately, measured at the sensor
Certificates & Standards
Approval marks – approval CE
Protection class III
Type of protection IP20
PRODUCT SHEET RELATING TO ENVIRONMENTAL QUALITIES AND CHARACTERISTICS
Quantity of precious metals 0 mg
Quantity of rare earths 0 mg
Minimum rate of recycled material in packaging 80 % 1)
Minimum percentage of recycled content in the product 0 % 1)
Product recyclability Mostly recyclable product 1)
Packaging recyclability Mostly recyclable packaging 1)
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage No
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage No
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
Product code Packaging unit (Pieces/Unit) Dimensions (length x width x height) Gross weight Volume
4008321916648 Folding box
1		 170 mm x 34 mm x 91 mm 93.00 g 0.53 dm³
4008321916655 Shipping box
10		 245 mm x 188 mm x 204 mm 961.40 g 9.40 dm³
User instruction / safety instructions
334180_LS/PD MULTI 3 CI – light and presence sensor for ceiling installation
PDF (273.3 KB)
Declarations of conformity
334067_LMS MULTI3 SENSORS
PDF (425.01 KB)
Product image: white background, diagonal
302465_LS/PD MULTI 3 CI
TIF (10.88 MB)
Product line drawing with letters
326400_EASY IR CI
SVG (22.87 KB)
Catalog info 1
Vivares sensor table
PDF (21.62 KB)
EAN SEG number STK number EFO number ELDAS number
4008321916648 7980301 2612504 3359114 535950200
